Description
One-view, single frame made of 4 mm steel fireplace and lined internally with cast-iron removable cast-iron plates. The chimney damper adjustment lever is located at the front of the door. It has an air curtain and secondary and tertiary combustion. Telescopic guides for smooth sliding doors.
| ΤΕΧΝΙΚΑ ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ / TECHNICAL DATA | ΜΟΝΑΔΑ ΜΕΤΡΗΣΗΣ / MEASURING UNIT | |
| Πλάτος / Width | cm | 97 |
| Βάθος / Depth | cm | 63 |
| Ύψος / Height | cm | 183 |
| Διαστάσεις στομίου εστίας (Π x Β x Υ) / Fireplace mouth measurement (W x D x H) | cm | 89 x 56 x 46 |
| Θερμική ισχύς / Thermal power | KW | 15,2 |
| Θερμική απόδοση / Efficiency | % | |
| Κατανάλωση καυσίμου (ξύλα) (min/max) / Fuel consumption (wood) | Kg/h | 1-5 |
| ø Έξοδος καυσαερίων / Smoke outlet | cm | 25 |
| Συνολικό βάρος / Total weight | Kg | 225 |
