Description
The middle – one side fireplaces R1V and Z1 of the MINI series are visually similar with the small width and high height of their hearth. But they have different depths: shallower 41 cm R1V and deeper Z1 with 54 cm. Respectively, the cross section of their chimney output is 16 cm for the R1V and 18 cm for the Z1. For complete combustion control, choose the S Thermatik NEO system. With the S-VENT set, they are converted into fan-heated fireplaces with forced circulation of hot air. With the option of turning the door clockwise or counterclockwise.
ΤΕΧΝΙΚΑ ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ / TECHNICAL DATA | ΜΟΝΑΔΑ ΜΕΤΡΗΣΗΣ / MEASURING UNIT | R1V -ΒΑΘΟΣ /DEPTH 41 cm | Z1-ΒΑΘΟΣ /DEPTH 54 cm |
Πλάτος / Width | cm | 54 | 54 |
Βάθος / Depth | cm | 46 | 59 |
Ύψος / Height | cm | 113 | 139 |
Διαστάσεις στομίου εστίας (Π x Β x Υ) / Fireplace mouth measurement (W x D x H) | cm | 45 x 41 x 52 | 45 x 54 x 52 |
Θερμική ισχύς / Thermal power | KW | 5,2 | 7,0 |
Θερμική απόδοση / Efficiency | % | 80 | 78 |
ø Έξοδος καυσαερίων / Smoke outlet | cm | 16 | 18 |
Συνολικό βάρος / Total weight | Kg | 121 | 164 |
