Description
The best choice for heating. Large combustion space, high efficiency and the ability to transport hot air to neighboring areas, with the superior quality of the CAMINODESIGN energy save fireplaces. Also suitable for baking. Available in natural flow or with hot air fan. Certified heater according to EN 13229. Our price for the air-fan version includes: double suction motor 800 m³ / h of German origin, relief louvre and two blinds for the hot air ducts. It is also available with a stainless-steel door at an extra cost of 160 €
ΤΕΧΝΙΚΑ ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ / TECHNICAL DATA | ΜΟΝΑΔΑ ΜΕΤΡΗΣΗΣ / MEASURING UNIT | |
Πλάτος / Width | cm | 100 |
Βάθος / Depth | cm | 59 |
Ύψος / Height | cm | 172 |
Θερμική ισχύς / Thermal power | KW | 13 |
Θερμική απόδοση / Efficiency | % | 70 |
Κατανάλωση καυσίμου (ξύλα) (min/max) / Fuel consumption (wood) | Kg/h | 4-6 |
ø Έξοδος καυσαερίων / Smoke outlet | mm | 250 |
ø Άνοιγμα εισαγωγής αέρα για την καύση / Outer air inlet dimensions | mm | 150 |
ø Παροχή αέρα αερόθερμου ( είσοδος ) / Fan heater air inlet ( intake) | mm | 2 X 120 |
ø Παροχή αέρα αερόθερμου ( έξοδος) / Fan heater air inlet (exit) | mm | 2 X 100 |
Συνολικό βάρος / Total weight | Kg | 290 |
CO ( σε 13% O2 ) | mg/Nm³ | 234,09 |
Θερμοκρασία εξόδου καυσαερίων ( μ.ο. ) / Smoke exit temperature (Avg.) | ˚C | 290 |
