Description
Fireplace upgrade energy cassettes INVICTA INSERT GRAND ANGLE. Made of cast iron with double back and cutter. They have a crystal cleaning system, secondary combustion, glass-ceramic glass, three places for grill. Built-in 2 fans, 2 speeds 320 cubic meters per hour. Certification according to UNE EN 13229. Factory warranty 5 years. The cassettes are made in France.
| ΤΕΧΝΙΚΑ ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ / TECHNICAL DATA | ΜΟΝΑΔΑ ΜΕΤΡΗΣΗΣ / MEASURING UNIT | ||
| Πλάτος / Width | cm | 70 | 80 |
| Βάθος / Depth | cm | 47 | 47 |
| Ύψος / Height | cm | 52 | 58 |
| Διαστάσεις κρυστάλλου (Π x Υ) / Glass dimensions (W x H) | cm | 61 x 40 | 71 x 46 |
| Ωφέλιμη ισχύς (min/max) / Useful heat output | KW | 10 | 12 |
| Απόδοση / Efficiency | % | 76 | 75 |
| Κατανάλωση καυσίμου (ξύλα) (min/max) / Fuel consumption (wood) | Kg/h | 3,3 | 4,0 |
| ø έξοδος καπνού / Ø Combustion product outlet | cm | 20 | 20 |
| ø παροχή αέρα / Ø External air intake | cm | 12 | 12 |
| Συνολικό βάρος / Total weight | Kg | 134 | 161 |
| CO | % | 0,12 | 0,15 |
| Ενεργειακή κλάση / Energy class | Α | Α |
